951/006 PICV PRESSURE INDEPENDENT MOTORIZED CONTROL BALANCING VALVE
2024-11-20
951/006 PICV PRESSURE INDEPENDENT MOTORIZED CONTROL BALANCING VALVE
951 Flowmaster™ Pressure independent control balancing valves - PICV offer the combined benefits of optimal modulating flow control valve, differential dynamic pressure balancing control, and manual balancing valve 每 all in one 每 for air-handling units, fresh air units. Cost saving: A single 3-in-1 PICV replaces three other valves saving on investment and installation cost. Safe: Balancing made safe during design, installation and remodeling for designers and installers. Comfortable: Increased comfort for users due to ensured balancing and precise modulating temperature control. Energy saving: Inbuilt fast response balancing regulator reduces energy consumption and pump size. The maximum flow setting (functionally similar to a static or manual balancing valve) is mechanically built into the valve. The dynamic pressurebalancing has been internalized and there are no external piping.
| Balancing valve |
| Flanged connection (BS EN1092-2) |
| Ductile iron body. Stainless steel AISI 304 internals |
| PN16 |
| 24VAC㊣10% 50/60HZ |
| IP54 |
| Ambient temp -10~50⊥ |
| Mechanical max flow setting on valve |
| Similar to 951/002 and 951/20 |
Features
100% valve authority is always achieved that＊s to the differential pressure balancing module
Precise balancing and high flow rates also in low pressure conditions
Automatic balancing of the flow across the valve regardless of pressure fluctuations in system
Normally closed actuators compatible with all control signals
Operational pressure up to 400 kPa
Continuously variable analog adjustment provides accurate preset function.
Control accuracy of up to 5% in use area
Low noise
Optional
Reference nos. and dimensions:
| Related Series | Series/Type | PN class | No. | Description | DN |
|---|---|---|---|---|---|
| 951 | 951/006 | PN16 | 951006555101 | FM FLANGE END DI DN65 PN16 BF P/T | DN65 |
| 951 | 951/006 | PN16 | 951008055101 | FM FLANGE END DI DN80 PN16 BF P/T | DN80 |
| 951 | 951/006 | PN16 | 951010055101 | FM FLANGE END DI DN100 PN16 BF P/T | DN100 |
| 951 | 951/006 | PN16 | 951012555101 | FM FLANGE END DI DN125 PN16 BF P/T | DN125 |
| 951 | 951/006 | PN16 | 951515055101 | FM FLANGE END DI DN150 PN16 BF P/T | DN150 |
